1、Product parameters

PRODUCT MODEL	supply voltage	Input power	output current	Product sizeLxWxH(mm)
INVCT301	380VAC 50/60Hz 415VAC 50/60Hz	20kW	40A	335 x 245 x 157
INVCT302		28kW	50A

2、characteristic:
Universalization:Covering a power range of 16-24HP, different compressors can be easily configured by dialing codes.

3、High reliability:
①Dual switch topology structure:Easily achieve standby power consumption<5W, meeting customers' energy-saving needs while extending the service life of capacitors;
②Compressor exhaust high pressure hardware protection:The compressor discharge is linked with the busbar relay to ensure the safety of the unit under extreme conditions;
③Three phase imbalance handling mechanism:Ensure reliable operation even under harsh grid quality conditions, with no degradation in service life;
④Pollution Level III+Full Coating:Ensure the reliable operation of products in harsh polluted environments;
⑤Double 85 and strife test：Comprehensive and multi-dimensional (voltage, temperature, and load) rigorous testing to ensure the normal operation of the product under extreme working conditions;
⑥Professional PCBA OEM factory:Ensure more reliable production quality of delivered products.
